FRP Transparent Roof Sheet
Product Feature for FRP transparent roof sheetFRP (Fiberglass Reinforced Plastic Panels) produce moisture-proof and impact-resistant sanitary environments in an array of decorative choices. ApplicationThe color of FRP sheet is transparent or translucent. It is widely used for natural lighting on wor......
Send Inquiry
Product Description
Product Feature for FRP transparent roof sheet
FRP (Fiberglass Reinforced Plastic Panels) produce moisture-proof and impact-resistant sanitary environments in an array of decorative choices.
Application
The color of FRP sheet is transparent or translucent. It is widely used for natural lighting on workshop, commercial building and civil buidling.
Specification
Width: 720mm/910mm/940mm/1088mm/1130mm
Length: Customized
Thickness: 0.8mm/1.0mm/1.2mm/1.5mm/2.0mm
Cover Width: 960mm
Purlin Distance: 660mm
Unit Length: 219mm
Lengthwise Overlap: 219mm
Technical data for FRP transparent roof sheet
Packaging and shipping
1. Pallet packaging
2. PE Bags Packaging
Company information
Founded in 1994, Laizhou Jieli Industrial Co., Ltd. is an 'ISO9001 :2008' certified company, which is specialized in the research, development, manufacture and supply of UPVC roofing sheet, Resin roof tile, Glass fiber reinforced resin roof tile and FRP roofing sheet for over 20 years.
2003 Successfully to produce advanced Jieli brand roof tile, which is Anti-UV. Long life time 50 years, colorfasting no change 20 years.
2004 passed ISO9001:2000 quality control system. Now we have passed ISO9001:2008.
2006 got environment friendly certificate
2007 got famous Brand by government.
2008 Signed government order for Olympic Games
2011 Nepal government officers visited JIELI company and placed orders
2012 The Venezuelan government purchase 200x20FCL containers.
2012 Make cooperation with France company, exported products to Europe market.
2013 Our products are sold in Homecenter, Buidling material supermarket.
2014 Jieli owned a Lab for testing the quality of the products to eusure high quality
Our client
-Canton Fair; BIG 5 Dubai; India ACE; FEICON; MOSBUILD exhibition
-Exporting to more than 135 countries, such as Latin America, Europe, Middle East, Africa, West and South-east Asia and Australasia.
FAQ
1. What machine do you use to cut for for Synthetic Resin Roof tile Roma style?
Using portable cutting machine.
2. What machine do you use to install the screws?
Portable electric drill.
3. How to install for for Synthetic Resin Roof tile Roma style?
Overlap, on the vertical direction overlap 150-200mm, on the horizontal direction overlap one wave.
4. What is the temerature limited of the environment that your roof can be used?
Temperature range: From Minus 35 degree to 72 degree
5. What color can you produce?
White, blue, brick red, green, grey etc, same as our color swatch. If you need special color, please provide sample.
6. Does you charge for the samples?
According to our company policy, we just sent free samples to customers while the customers bear the freight fees.
7. Can you produce according to customers'design?
Sure, we are professional manufacturer,OEM are welcome . But the beginning you need pay the mould open fees,after certain quantity, the open mould fees will be returned as product.
Supply high quality roof material and best solution !
Know more details, pls send email with your inquiry details!
FRP (Fiberglass Reinforced Plastic Panels) produce moisture-proof and impact-resistant sanitary environments in an array of decorative choices.
Application
The color of FRP sheet is transparent or translucent. It is widely used for natural lighting on workshop, commercial building and civil buidling.
Specification
Width: 720mm/910mm/940mm/1088mm/1130mm
Length: Customized
Thickness: 0.8mm/1.0mm/1.2mm/1.5mm/2.0mm
Cover Width: 960mm
Purlin Distance: 660mm
Unit Length: 219mm
Lengthwise Overlap: 219mm
Technical data for FRP transparent roof sheet
| ITEM | DATA |
| Tensile strength(Mpa) | 155 |
| Tensile modulus(Gpa) | 7.75 |
| Bending Strength (Mpa) | 223 |
| Bending modulus (Gpa) | 8.3 |
| Wet flexural strength (Mpa) | 217 |
| Wet flexural modulus (Gpa) | 8.43 |
| Determination of the punch-type shear(Mpa) | 125 |
| Coefficient of thermal expansion | 2.5x10 |
| Barcol hardness | 52 |
| water absorption (%) | 0.126 |
| distortion temperature (?) | 200 |
| coefficient of heat conductivity w/w.k | 0.156 |
| specific gravity(g/m2) | 1.4 |
| Application temperature range (?) | FROM -40 TO130 |
| flash(ing) point (?) | 410 |
| UV proof (%) | 99.99 |
Packaging and shipping
1. Pallet packaging
2. PE Bags Packaging
Company information
Founded in 1994, Laizhou Jieli Industrial Co., Ltd. is an 'ISO9001 :2008' certified company, which is specialized in the research, development, manufacture and supply of UPVC roofing sheet, Resin roof tile, Glass fiber reinforced resin roof tile and FRP roofing sheet for over 20 years.
2003 Successfully to produce advanced Jieli brand roof tile, which is Anti-UV. Long life time 50 years, colorfasting no change 20 years.
2004 passed ISO9001:2000 quality control system. Now we have passed ISO9001:2008.
2006 got environment friendly certificate
2007 got famous Brand by government.
2008 Signed government order for Olympic Games
2011 Nepal government officers visited JIELI company and placed orders
2012 The Venezuelan government purchase 200x20FCL containers.
2012 Make cooperation with France company, exported products to Europe market.
2013 Our products are sold in Homecenter, Buidling material supermarket.
2014 Jieli owned a Lab for testing the quality of the products to eusure high quality
Our client
-Canton Fair; BIG 5 Dubai; India ACE; FEICON; MOSBUILD exhibition
-Exporting to more than 135 countries, such as Latin America, Europe, Middle East, Africa, West and South-east Asia and Australasia.
FAQ1. What machine do you use to cut for for Synthetic Resin Roof tile Roma style?
Using portable cutting machine.
2. What machine do you use to install the screws?
Portable electric drill.
3. How to install for for Synthetic Resin Roof tile Roma style?
Overlap, on the vertical direction overlap 150-200mm, on the horizontal direction overlap one wave.
4. What is the temerature limited of the environment that your roof can be used?
Temperature range: From Minus 35 degree to 72 degree
5. What color can you produce?
White, blue, brick red, green, grey etc, same as our color swatch. If you need special color, please provide sample.
6. Does you charge for the samples?
According to our company policy, we just sent free samples to customers while the customers bear the freight fees.
7. Can you produce according to customers'design?
Sure, we are professional manufacturer,OEM are welcome . But the beginning you need pay the mould open fees,after certain quantity, the open mould fees will be returned as product.
Supply high quality roof material and best solution !
Know more details, pls send email with your inquiry details!
