China Changzhou Fire Resistant Exhibition Raised Floor System with Carpet
HT 600*600 Raised Access Floor is made of good quality cold-rolled steel sheet, which is stretched, spot-welded, and coated with epoxy powder after having been phosphoreted. There is foaming cement fully filled, with corner-lock holes punched in four sides of the panel.Application5A class office bui......
Send Inquiry
Product Description
HT 600*600 Raised Access Floor is made of good quality cold-rolled steel sheet, which is stretched, spot-welded, and coated with epoxy powder after having been phosphoreted. There is foaming cement fully filled, with corner-lock holes punched in four sides of the panel.
Application
5A class office building, intelligent office environment, meeting room, commercial and industrial bureau, government, places that have requirements of dust-proof and water-proof, fields with aerial requirements. 610/24" Steel Panels are mainly welcomed by Japanese, Korean and domestic market.
Characteristics
Designed specially for office building
Excellent rolling load & ultimate load performance
Light weight cementitious fill makes panels solid and quiet
Completely noncombustible
Black electrodeposition cathodic epoxy paint finish for life time protection
Class A flame spread and smoke development rating
All-steel pedestals provide excellent impact load performance
Technical Paramter
Application
5A class office building, intelligent office environment, meeting room, commercial and industrial bureau, government, places that have requirements of dust-proof and water-proof, fields with aerial requirements. 610/24" Steel Panels are mainly welcomed by Japanese, Korean and domestic market.
Characteristics
Designed specially for office building
Excellent rolling load & ultimate load performance
Light weight cementitious fill makes panels solid and quiet
Completely noncombustible
Black electrodeposition cathodic epoxy paint finish for life time protection
Class A flame spread and smoke development rating
All-steel pedestals provide excellent impact load performance
Technical Paramter
| Type | Size | Uniform load | Concentrated load | Rolling load | Impact load | Ultimate load | ||
| 0.100''/2.5mm DEFLECTION | 10PASS | 10KPAAASS | ||||||
| FS662 | 600*600*35mm | 14.71KN/ | 2.94KN | 300KG | 2.45KN | 2.00KN | 100LB/45KG | 8.85KN |
| 610*610*35mm | ||||||||
| FS800 | 600*600*35mm | 17.78KN/ | 3.56KN | 363KG | 2.94KN | 2.45KN | 100LB/45KG | 11.25KN |
| 610*610*35mm | ||||||||
| FS1000 | 600*600*35mm | 22.22KN/ | 4.45KN | 454kG | 3.56KN | 2.67KN | 150LB/68KG | 14.50KN |
| 610*610*35mm | ||||||||
| FS1250 | 600*600*35mm | 27.78KN/ | 5.56KN | 567KG | 4.45KN | 3.56KN | 150LB/68KG | 18.36KN |
| 610*610*35mm | ||||||||
| FS1500 | 600*600*35mm | 33.34KN/ | 6.68KN | 680KG | 5.56KN | 4.45KN | 175LB/68KG | 22.17KN |
| 610*610*35mm | ||||||||
| FS2000 | 600*600*35mm | 44.45KN/ | 8.89KN | 907KG | 6.67KN | 5.56KN | 175LB/79KG | 29.42KN |
| 610*610*35mm | ||||||||
